CE - Ceratizit
CE - Ceratizit

turning insert

Identifying order number: 11530120

Product name: DNMG 150612EN-TM CTCP125

DIN4000-76-3 - Rhombic inserts Rhombic inserts SPJ3

keyboard_arrow_right

More

type-helpImage Tool class graphic - ISO13399-Rhombic insert
picture picture - CE - Ceratizit - 11530120
Geometric data
201-03 (ISO)
INSI (GTC)
SPJ3 (DIN4000)
Description Value
J21 Identifying order number 11530120
J22 Product name DNMG 150612EN-TM CTCP125
J3 Company code CE - Ceratizit
NSM Standard number of properties layout DIN4000-76
BLD Tool style code 3
A1 Insert included angle 55 Degree
A2 Clearance angle major 0 Degree
B1 Cutting edge length 0.610236 in
B3 Inscribed circle diameter 0.500000 in
C1 Insert thickness 0.250000 in
D1 Corner radius 0.047244 in
E41 Cutting edge condition code E - Rounded
E6 Chip breaker face count 2 - With chip breaker on both sides
E9 Chip breaker manufacturers designation TM
F1 Insert hand N - Neutral
G1 Tolerance class insert M
G4 Insert thickness total 0.250000 in
G5 Insert mounting style code 2 - With cylindrical bore
G6 Fixing hole diameter 0.203150 in
H11 Standard designation of the grade, main application HC-P25
H12 Standard designation of the grade, 2nd application HC-M20
H13 Standard designation of the grade, 3rd application HC-K30
H2 Coolant supply property 0 - Without coolant supply
H3 Grade manufacturer's designation CTCP125
H5 Coating TiCN+Al2O3
ISISO ISO property 0
J11 Standard designation DNMG150612EN
J11A Standard designation ANSI DNMG443EN
Working process
No working processes available
Connection codes

J6 / J441 - connection code machine end Matching components

DIN
DN1506122N
