Geometric data
Tool class graphic Tool class graphic - ISO13399-Non-centre cutting single row end mill
Description Value
J21 Identifying order number 7 32 266
J22 Product name
J22A Product name, inch alternative
V20 Order number 3
J3 Company code POKO - Pokolm
NSM Standard number of properties layout DIN4000-87
BLD Tool style code 1
A1 Cutting diameter 1.102362 in
A1A Cutting edge angle major, Pos. A 0 Degree
A2A Clearance angle major, Pos. A 7 Degree
A3 Body diameter
A5 Neck diameter 0.629921 in
B1A Cutting edge length, Pos. A 0.244094 in
B2 Depth of cut maximum 0.039370 in
B2A Insert width, Pos. A
B3 Protruding length
B3A Inscribed circle diameter, Pos. A
B4 Usable length
B5 Overall length 2.165354 in
B6 Head length
B71 Functional length
B9 Shoulder length
BLDA Tool style code Position A 99
C13 Connection thread nominal size machine side M16
C1A Insert thickness, Pos. A 0.086614 in
C31 ISO-tolerance class shank diameter
C32 Shank diameter, upper limit
C33 Shank diameter, lower limit
C4 Shank length
D11 Mill tool type ISO
D1A Corner radius, Pos. A 0.078740 in
D2A Corner chamfer length, Pos. A
D3A Corner chamfer angle, Pos. A
D4A Cutting edge angle major, Pos. A
D5 Balance quality code
D6 Rotational speed maximum
D6A Wiper edge length, Pos. A
D7 Weight of item 0.212 kg
D9 Adjustment property 0 - Adjustment not possible
E1 Tool cutting edge angle
E2 Rake angle axial -4 Degree
E3 Rake angle radial -4 Degree
E4 Ramping angle maximum 1 Degree
E5 Plunge depth maximum 0.027559 in
E71 Transition angle 1
E72 Transition angle 2
E73 Transition radius 1
E74 Transition radius 2
F1 Cutting direction R - Right
F21 Peripheral effective cutting edge count 7
F22 Face effective cutting edge count 7
F23 Number of mounting layers 1
F24 Cutting item count per mounting layer 7
F8 Connection count machine side 1
G22 Cutting item type count
G23 Cutting item count 7
H21 Coolant entry style code 1 - With Coolant entry, axial concentric
H22 Coolant exit style code 3 - With Coolant exit, axial and radial
H4 Body material code S - Solid steel
ISISO_A Indicator for ISO cutting plate Pos.A 0
J1 Standard
J11 Standard letter to the standard number
J12 Style identifier manufacturers specific
J24 Dataset Composition
J7 Data chip provision 0 - Without data chip
Working process
Working process
FFO - Die milling
FNU - Groove milling
FPL - Face milling
FZI - Circular milling
Connection codes

J44 / J441 - Insert (CSW1_1,​CSW1_2,​CSW1_3,​CSW1_4,​CSW1_5,​CSW1_6,​CSW1_7) Matching components

Block index Corner radius Clamping type code 1st step Master insert type count Master insert identification
IND G14 G21 G25 J45
1
error_outline
error_outline
error_outline
error_outline
XCHW062220EN
error_outline
Manufacturer specific (DIN)
POKO-XC0622

J6 / J61 - connection code machine end Matching components

Type Size code Form Unit base Style Diameter Tolerance class coded
C11 C2 C12 C14 C15 C3 C16
SAD
Screw mounting
0160
01
1
Metric with coolant
5
Shaft in machine direction or hole in workpiece direction
16 mm
Manufacturer specific (DIN)
POKO-XC0622
